Larger energy capacity
Longer cycle life
Lighter weight
High power
Wider temperature range
Superior Safety
Accurate power calculation
Application: Data room, power grid-
connected and off-grid, large-scale energy storage .etc
Model | LFP96100 | LFP96200 |
Electrical Parameter | ||
Rate voltage | 96V | |
Rate capacity | 100AH | 200AH |
Energy | 9.6KWh | 19.2KWh |
Cycle life | > 4000 cycles 80% DOD | |
Designed life | 10 Years | |
Operating Parameter | ||
Charge voltage | 106V | |
Charge current | 50A | 100A |
Max.Charge current | 100A | 200A |
Discharge cut-off voltage | 75V | |
Discharge current | 50A | 100A |
Max.Discharge current | 100A | 200A |
Discharge temperature | -20~55℃ | |
Charge temperature | 0~55℃ | |
Storage temperature | -10~45℃ | |
Function items | ||
Communication port | RS485 / CAN | |
Display | LCD | |
Manchanical Parameter | ||
Terminal | Anderson / Connector | |
Weight | 100KG | 180KG |
Dimension(Wx D x H)mm | 440x650x170mm (6U) | 440x650x170mm(12U) |
Protection | IP20 | |
Standard | ||
Certification | CE | |
